Fuji K-Series KW Double Foot Casting/Spinning Guides - Torzite
Specifications
Fuji K-Series KW Double Foot Casting/Spinning Guides - Torzite
Product Details
Fuji’s KW Series guides are built on the proven K-Series platform, offering a rugged double-foot frame with a sloped, tangle-free design optimized for both casting and spinning rod builds. Engineered to handle the demands of modern fishing techniques, KW guides provide strength, control, and exceptional performance across a wide range of applications—from freshwater bass rods to saltwater surf and boat rods.
Key Features:
- Tangle-Free K-Series Design: Sloped frame eliminates line wrap, especially with braided lines.
- Double-Foot Frame Construction: Provides maximum strength and stability for heavy-duty use.
- Multiple Ring Options: Available with Fuji’s full lineup of ring materials including Torzite®, SiC, Alconite®, Fazlite®, and Concept “O” – covering every performance need and price point.
- Corrosion-Resistant Frame Finishes: Choose from standard stainless steel or premium corrosion-control options for saltwater environments.
- KR Concept Compatible: Ideal as part of a KR Concept layout for enhanced line control and reduced weight.
-
Recommended For:
Spinning and casting rods used in freshwater, inshore, offshore, and surf environments. Perfect for custom rod builders seeking a high-performance, versatile guide series.
KR Guide Placement Software
Size Chart
| Ring Size | Height (mm) | L1 Rear Foot (mm) | L2 Front Foot (mm) | Length (mm) |
|---|---|---|---|---|
| 5.5 | 7.6 | 5.1 | 4.7 | 17.7 |
| 6 | 8.7 | 5.3 | 4.8 | 20.0 |
| 7 | 10.3 | 5.6 | 5.0 | 20.9 |
| 8 | 12.3 | 6.0 | 5.9 | 25.2 |
| 10 | 14.6 | 7.0 | 6.8 | 29.2 |
| 10M | 18.1 | 9.8 | 8.0 | 36.5 |
| 12 | 17.4 | 8.0 | 8.0 | 33.4 |
| 12M | 25.6 | 12.1 | 10.0 | 43.3 |
| 16 | 21.2 | 9.5 | 9.5 | 43.0 |
| 20 | 28.6 | 11.0 | 11.3 | 50.2 |
| 25 | 41.2 | 14.0 | 14.3 | 61.9 |
| 30 | 49.4 | 16.3 | 14.0 | 71.5 |
| 30L | 59.6 | 16.0 | 16.4 | 76.6 |
| 40 | 59.7 | 20.0 | 18.0 | 96.6 |
| 40L | 59.7 | 20.2 | 18.0 | 90.0 |
| 50 | 85.1 | 24.1 | 24.6 | 113.4 |
Note: Frame Height Codes – L = Low, M = Medium
Warning: California's Proposition 65
Proposition 65 Warning
CA WARNING.
WARNING: This product can expose you to chemicals including Lead, which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to https://www.P65Warnings.ca.gov
Files & Documents
Love theses guides, a little pricey but definitely worth it!
Worth it
Hunter was awesome! I sent him bunch of images and measurements of broken guide and he was able to locate the exact one. Great outfit. Would not go anywhere else.
Best guides on the market. The feet on anything larger than a 6 still need to be fit but that is rod making. I love these guides, I can't get anyone to want to pay for them but myself but they always ask why is my pole so much smoother to use. 100% torzite all the way!
Fuji K-Series Double-Foot Casting & Spinning Guides Model KW - Torzite
I use them on fly rod to reduce friction on first 2 guides.they are light and work great
Appear to be an excellent guide but won’t know until Spring when the rod gets used hard. Lighter, so the build should have better performance, nice appearance, but are they worth the cost? Can the average fisherman tell the difference between Torzite and a Fuji Alconite guide train? Use for the discriminating angler where cost is not an issue.
What is difference of 30 & 30L guide set
The difference between the 30 and 30L guides is going to be the frame height. Both will have the exact same size ring but the 30L is going to have a shorter frame and the ring will sit closer to the rod blank.
