TiForged Double Foot Spin/Cast Guides TDF - Nanolite

4.8

TiForged Double Foot Spin/Cast Guides TDF - Nanolite

American Tackle Co.

SKU: NBTDF-5.5

$2.89 USD

Ring Type: Nanolite

Duralite Nanolite Pentalite

Color:

Black

Size:

5.5

Size Chart - TiForged TDF Double Foot Guides

SS Frame - Duralite Ring
Size	Height A	Height B	Height C	Weight	Ring ID	Foot 1	Foot 2	Total Length
5.5	2.60 mm	6.15 mm	7.40 mm	0.25 gm	3.50 mm	5.00mm	5.00 mm	19.00 mm
6	3.05 mm	7.00 mm	8.50 mm	0.33 gm	4.00 mm	5.50 mm	5.00 mm	20.20 mm
7	3.55 mm	8.15 mm	9.80 mm	0.53 gm	4.95 mm	5.50 mm	5.50 mm	21.80 mm
8	4.85 mm	10.05 mm	12.40 mm	0.70 gm	5.60 mm	5.50 mm	5.50 mm	24.20 mm
10	5.50 mm	12.50 mm	15.20 mm	1.15 gm	7.40 mm	7.00 mm	6.50 mm	26.50 mm
12	6.00 mm	14.15 mm	23.00 mm	1.50 gm	8.85 mm	10.00 mm	9.00 mm	39.00 mm
16	8.45 mm	17.80 mm	23.00 mm	2.60 gm	11.00 mm	10.00 mm	9.00 mm	39.00 mm
20	10.15 mm	24.25 mm	29.00 mm	4.10 gm	14.46 mm	12.20 mm	11.00 mm	51.00 mm
25	22.60 mm	40.00 mm	44.50 mm	7.90 gm	18.75 mm	15.00 mm	15.00 mm	59.00 mm
30	34.15 mm	56.75 mm	64.00 mm	11.00 gm	24.60 mm	16.50 mm	16.00 mm	68.00 mm
30L	24.30 mm	47.00 mm	49.50 mm	9.60 gm	24.60 mm	15.00 mm	15.00 mm	63.70 mm
40L	31.00 mm	56.80 mm	62.00 mm	17.2 gm	28.60 mm	18.00 mm	18.50 mm	90.50 mm
50L	32.60 mm	74.80 mm	80.00 mm	24.00 gm	40.40 mm	24.00 mm	24.50 mm	105.00 mm

SS Frame - Nanolite Ring
Size	Height A	Height B	Height C	Weight	Ring ID	Foot 1	Foot 2	Total Length
5.5	2.60 mm	6.15 mm	7.40 mm	0.25 gm	2.75 mm	5.00mm	5.00 mm	19.00 mm
6	3.05 mm	7.00 mm	8.50 mm	0.30 gm	4.25 mm	5.50 mm	5.00 mm	20.20 mm
7	3.55 mm	8.15 mm	9.80 mm	0.50 gm	4.90 mm	5.50 mm	5.50 mm	21.80 mm
8	4.85 mm	10.05 mm	12.40 mm	0.67 gm	5.85 mm	5.50 mm	5.50 mm	24.20 mm
10	5.50 mm	12.50 mm	15.20 mm	1.10 gm	7.75 mm	7.00 mm	6.50 mm	26.50 mm
12	6.00 mm	14.15 mm	23.00 mm	1.40 gm	9.15 mm	10.00 mm	9.00 mm	39.00 mm
16	8.45 mm	17.80 mm	23.00 mm	2.50 gm	11.60 mm	10.00 mm	9.00 mm	39.00 mm
20	10.15 mm	24.25 mm	29.00 mm	3.90 gm	15.00 mm	12.20 mm	11.00 mm	51.00 mm
25	22.60 mm	40.00 mm	44.50 mm	7.70 gm	19.30 mm	15.00 mm	15.00 mm	59.00 mm
30	34.15 mm	56.75 mm	64.00 mm	10.80 gm	24.90 mm	16.50 mm	16.00 mm	68.00 mm
30L	24.00 mm	47.30 mm	49.50 mm	9.40 gm	25.10 mm	15.00 mm	15.00 mm	63.70 mm
40L	30.50 mm	57.30 mm	62.00 mm	16.30 gm	29.60 mm	18.00 mm	18.50 mm	90.50 mm
50L	32.60 mm	74.80 mm	80.00 mm	24.00 gm	40.40 mm	24.00 mm	24.50 mm	105.00 mm

Titanium Frame - Nanolite Ring
Size	Height A	Height B	Height C	Weight	Ring ID	Foot 1	Foot 2	Total Length
5.5	2.60 mm	6.15 mm	7.40 mm	0.17 gm	2.75 mm	5.00mm	5.00 mm	19.00 mm
6	3.05 mm	7.00 mm	8.50 mm	0.24 gm	4.25 mm	5.50 mm	5.00 mm	20.20 mm
7	3.55 mm	8.15 mm	9.80 mm	0.31 gm	4.90 mm	5.50 mm	5.50 mm	21.80 mm
8	4.85 mm	10.05 mm	12.40 mm	0.40 gm	5.85 mm	5.50 mm	5.50 mm	24.20 mm
10	5.50 mm	12.50 mm	15.20 mm	0.64 gm	7.75 mm	7.00 mm	6.50 mm	26.50 mm
12	6.00 mm	14.15 mm	23.00 mm	1.00 gm	9.15 mm	10.00 mm	9.00 mm	39.00 mm
16	8.45 mm	17.80 mm	23.00 mm	1.77 gm	11.60 mm	10.00 mm	9.00 mm	39.00 mm
20	10.15 mm	24.25 mm	29.00 mm	2.60 gm	15.00 mm	12.20 mm	11.00 mm	51.00 mm
25	22.60 mm	40.00 mm	44.50 mm	4.90 gm	19.30 mm	15.00 mm	15.00 mm	59.00 mm
30	34.15 mm	56.75 mm	64.00 mm	7.20 gm	24.90 mm	16.50 mm	16.00 mm	68.00 mm
30L	24.00 mm	47.30 mm	49.50 mm	6.70 gm	25.10 mm	15.00 mm	15.00 mm	63.70 mm
40L	30.50 mm	57.30 mm	62.00 mm	11.00 gm	29.60 mm	18.00 mm	18.50 mm	90.50 mm
50L	32.60 mm	74.80 mm	80.00 mm	21.00 gm	40.40 mm	24.00 mm	24.50 mm	105.00 mm

Titanium Frame - Duralite Ring
Size	Height A	Height B	Height C	Weight	Ring ID	Foot 1	Foot 2	Total Length
5.5	2.60 mm	6.15 mm	7.40 mm	0.17 gm	3.50 mm	5.00mm	5.00 mm	19.00 mm
6	3.05 mm	7.00 mm	8.50 mm	0.25 gm	4.00 mm	5.50 mm	5.00 mm	20.20 mm
7	3.55 mm	8.15 mm	9.80 mm	0.32 gm	4.95 mm	5.50 mm	5.50 mm	21.80 mm
8	4.85 mm	10.05 mm	12.40 mm	0.45 gm	5.60 mm	5.50 mm	5.50 mm	24.20 mm
10	5.50 mm	12.50 mm	15.20 mm	0.70 gm	7.40 mm	7.00 mm	6.50 mm	26.50 mm
12	6.00 mm	14.15 mm	23.00 mm	1.05 gm	8.85 mm	10.00 mm	9.00 mm	39.00 mm
16	8.45 mm	17.80 mm	23.00 mm	1.90 gm	11.00 mm	10.00 mm	9.00 mm	39.00 mm
20	10.15 mm	24.25 mm	29.00 mm	2.80 gm	14.46 mm	12.20 mm	11.00 mm	51.00 mm
25	22.60 mm	40.00 mm	44.50 mm	5.20 gm	18.75 mm	15.00 mm	15.00 mm	59.00 mm
30	34.15 mm	56.75 mm	64.00 mm	7.60 gm	24.60 mm	16.50 mm	16.00 mm	68.00 mm
30L	24.30 mm	47.00 mm	49.50 mm	6.90 gm	24.60 mm	15.00 mm	15.00 mm	63.70 mm
40L	31.00 mm	56.80 mm	62.00 mm	12.00 gm	28.60 mm	18.00 mm	18.50 mm	90.50 mm
50L	32.60 mm	74.80 mm	80.00 mm	21.00 gm	40.40 mm	24.00 mm	24.50 mm	105.00 mm

Variant

In stock

Quantity:

Free Shipping

Orders $99+ to USA lower 48. More →

Free Returns

100% Satisfaction guaranteed. More →

Specifications

SKU	NBTDF-5.5
Color	Black
Fishing technique	Spinning
Height	7.4 mm
Height bottom	2.6 mm
Height top	6.15 mm
Length	19 mm
Length foot 1	5 mm
Length foot 2	5 mm
Material	Stainless Steel
Ring inside diameter	2.75 mm
Ring material	Nanolite
Ring size	5.5
Weight	0.25 g

About American Tackle Co.

American Tackle sets the standard for innovative, high-quality, premier rod building components that every angler can trust. With over 30 years of experience in the tackle industry, American Tackle takes pride in delivering unmatched variety, durability, and, most importantly, performance.

American Tackle Co.TiForged Double Foot Spin/Cast Guides TDF - Nanolite

$2.89 USD

TiForged Double Foot Spin/Cast Guides TDF - Nanolite

Product Details

316SS or solid Titanium alloy frames
Snagless frame designs in spinning and casting configurations
Hardened frames for extreme strength, keeping rings secure and safe from frame deformation
Slim ring design to reduce weight and polished round for increased casting distances and extended line life
Available with American Tackle proprietary Nanolite or Duralite ring options
American Tackle's ceramic rings provide a near zero coefficient of friction with wet line — extending line life while increasing hardness to that of Silicone Carbide (SiC)
